SolaX X3-HAC-22P EV Charger G2 – Fast, Smart & Solar-Optimized Charging for Every Installation

As the demand for electric vehicles and home energy optimization skyrockets across Europe, one name stands out for forward-thinking solar-integrated charging: SolaX Power. Their X3-HAC-22P Smart EV Charger represents the next generation of EV infrastructure, tailored for solar PV system owners, installers, solar wholesalers, and energy storage specialists alike.

🔌 What Makes the SolaX X3-HAC-22P the Smart Choice?

The X3-HAC-22P is part of the second-generation SolaX EV Charger G2 family, engineered for three-phase 400V installations with a powerful AC output of up to 22kW. It's a high-speed solution that integrates directly with existing or new solar panel systems, enabling users to charge their EVs 100% with green solar power, automatically balancing power draw between grid, PV, and battery in real time.

✅ Key Technical Highlights

• AC Input Voltage: 400V (Three-phase)

• Output Current: 6-32A

• Max Power: 22kW

• Smart Switching: Auto switch between 1P/3P for max efficiency

• Cable & Plug Type: Type 2 (6.5m)

• Mounting: Wall or pedestal (optional)

• Enclosure Protection: IP65/IP54 rated

• Smart Features:

  • Dynamic load balancing

  • RFID & App control

  • OCPP 1.6 / Modbus TCP compatibility

  • WiFi / Ethernet / 4G / RS485 options

• Monitoring: Fully integrated with Solax APP and LCD display

• Safety & Compliance: Full suite of protections incl. overvoltage, grounding, surge, cable lock, relay weld detection

• Standards: IEC 61851-1:2017 / IEC 62196-2:2016 compliant



🌞 Optimized for Solar & Energy Storage Integration

The built-in smart PV prioritization system ensures that solar power is always used first before pulling from the grid. Whether you're using SolaX hybrid inverters or other popular solar inverter brands, the X3-HAC-22P offers full interoperability, thanks to its multiple communication protocols and open-standard design.

With dynamic load balance via CT/meter input, the charger protects your home's total load and shifts power intelligently between home loads, energy storage batteries, and your EV.

📈 As shown in the solution diagram (page 2 of the datasheet), the system architecture supports seamless coordination between PV, battery, grid, and home consumption – ensuring maximum efficiency and safety.

💼 Ideal for Residential & Commercial Applications

Whether you're a solar installer setting up a smart home EV system, or a solar wholesaler delivering scalable infrastructure to EV fleets, the SolaX X3-HAC-22P delivers the flexibility and reliability required for both public and private deployments.

Thanks to APP-based access, real-time RFID authentication, and cloud-ready monitoring, it's also suitable for destination charging stations or shared multi-user environments.

🛒 Available Now at PV Solar Store – B2B & B2C Ready

The SolaX X3-HAC-22P EV Charger with Cable & Plug is in stock now at PV Solar Store, your trusted solar PV supplier, solar wholesaler, and energy storage distributor across the EU.

✅ No MOQ
✅ Real-time stock access
✅ Fast delivery across Europe
✅ Expert support for installers and EPCs
