Solplanet ASW8000H-T3 AFCI Asymmetric 8kW Three-Phase Hybrid Inverter
Key Features:
- 8kW three-phase hybrid inverter with asymmetric EPS output
- 3 independent MPPT trackers for flexible PV array design
- Supports up to 12000Wp PV input with 150% PV oversizing
- High-voltage LiFePO4 battery support from 120V to 600V
- IP66 outdoor protection with UPS-level switching below 10ms
In stock
Please sign in to add to cart.
Details
The Solplanet ASW8000H-T3 AFCI asymmetric is an advanced 8kW three-phase hybrid inverter designed for residential and small commercial solar PV systems with energy storage. With up to 12000Wp PV array power, 1100V maximum DC input, 3 independent MPPT trackers, and 16A input current per MPPT, it offers flexible solar panel design for modern rooftops, bifacial modules, and multi-orientation PV arrays. The inverter supports high-voltage LiFePO4 batteries from 120V to 600V and delivers up to 8000W charging and discharging power, making it a strong solution for complete solar kits and energy storage systems. In EPS mode, the ASW8000H-T3 supports 100% unbalanced three-phase AC output, helping critical loads operate more flexibly during grid outages. With UPS-level switching below 10ms, IP66 protection, natural convection cooling, CAN BMS, RS485 smart meter interface, WiFi/LAN communication, and Solplanet App setup, it is ideal for solar installers, solar wholesalers, solar distributors, and professional PV projects.
AFCI in solar inverters means Arc Fault Circuit Interrupter, a safety function that detects dangerous electrical arcs on the DC side of a solar PV system. If an arc fault is detected, the solar inverter can shut down the circuit to reduce fire risk.
Datasheet
Data
Manufacturer
Solplanet
Inverter Type
Hybrid
No. of Phases
3
Nominal AC Power
8kW
Item number
solplanet-asw8000h-t3-afci-asymmetric-8kw-three-p
Weight
26 kg/pcs
