Solplanet ASW5000H-T2 AFCI Asymmetric 5kW Three-Phase Hybrid Inverter
Key Features:
- 5kW three-phase hybrid inverter with asymmetric EPS output
- Supports up to 7500Wp PV input with 150% PV oversizing
- 2 MPPT trackers with 20A input current for modern solar panels
- High-voltage LiFePO4 battery support from 120V to 600V
- IP66 outdoor design with UPS-level switching below 10ms
In stock
Please sign in to add to cart.
Details
The Solplanet ASW5000H-T2 AFCI asymmetric is a compact 5kW three-phase hybrid inverter designed for residential and small commercial solar PV systems with energy storage. It supports up to 7500Wp PV array power, 1100V maximum DC input, 2 independent MPPT trackers, and 20A input current per MPPT, making it suitable for modern high-power solar panels, bifacial modules, and flexible rooftop layouts. The inverter works with high-voltage LiFePO4 batteries from 120V to 600V and provides up to 5000W charging and discharging power. In EPS mode, it supports 100% unbalanced three-phase AC output, helping supply critical loads more flexibly during outages. With UPS-level switching under 10ms, IP66 outdoor protection, natural convection cooling, smart meter interface, CAN BMS, WiFi/LAN communication, and Solplanet App setup, the ASW5000H-T2 is a strong choice for solar installers, solar distributors, solar wholesalers, and complete solar kits
AFCI in solar inverters means Arc Fault Circuit Interrupter, a safety function that detects dangerous electrical arcs on the DC side of a solar PV system. If an arc fault is detected, the solar inverter can shut down the circuit to reduce fire risk.
Datasheet
Data
Manufacturer
Solplanet
Inverter Type
Hybrid
No. of Phases
3
Nominal AC Power
5kW
Item number
solplanet-asw5000h-t2-afci-asymmetric-5kw-three-p
Weight
25 kg/pcs
